Description
Camec 3 Point Lock Barrel & Key,
Removing lock barrel
After removing lock assembly from the door, hold the handle open and turn and pull the rear metal lock activator (cylinder).
To remove the key barrel, working from the rear, depress the small metal wafer into the lock while the lock is rotated so the square protrusions on the lock line up with the gaps in the housing. The lock should now slide out the front.
To Add the lock barrel
Place the key in the lock and turn so the square protrusions on the lock line up with the gaps in the housing. Place the barrel at an angle so the wafer enters the housing first and depresses itself while the remainder of the lock to pushed in. The wafer should pop out to secure the lock in place.
These are for CAMEC 3 point door locks. We can not guarantee they will worth with anything else.
Features
1 year warranty.
Camec 3 Point Lock Barrel & Key,
Removing lock barrel
After removing lock assembly from the door, hold the handle open and turn and pull the rear metal lock activator (cylinder).
To remove the key barrel, working from the rear, depress the small metal wafer into the lock while the lock is rotated so the square protrusions on the lock line up with the gaps in the housing. The lock should now slide out the front.
To Add the lock barrel
Place the key in the lock and turn so the square protrusions on the lock line up with the gaps in the housing. Place the barrel at an angle so the wafer enters the housing first and depresses itself while the remainder of the lock to pushed in. The wafer should pop out to secure the lock in place.
These are for CAMEC 3 point door locks. We can not guarantee they will worth with anything else.
Features
1 year warranty.
You Might Also Be Interested in
Camec
CAMEC 3P DR REMOTE LATCH LH 014387
$39.95
Wodonga InStock
Canberra No Stock
Camec
Door Lock Inner - Camec 3 Point - Handle Kit -014381
$55.00
Wodonga InStock
Canberra No Stock
Camec
DOOR HANDLE -CAMEC 3P DR - MAIN LOCK LH 014384
$119.00
Wodonga InStock
Canberra InStock
Camec
DOOR HANDLE -CAMEC 3 POINT DOOR - MAIN LOCK RIGHT HAND HINGE 014385
$119.00
Wodonga InStock
Canberra InStock
Camec
CAMEC 3P DR REMOTE LATCH LH 014386
$39.95
Wodonga InStock
Canberra No Stock
Camec
Camec Tri Door 4 Piece Hinge 014407
